Concrete Pipe Testing Machine
Concrete pipe testing machines are consisting of a frame and a hydraulic power pack. The frame consist of 2 extra rigid columns and carrying chassis. A double acting actuator is integrated on the upper beam .The actuator has an anti-rotation system to prevent the natural tendency of the actuator to rotate. Load cell is used for precise load measurement and closed loop control.
Upper beam height pre-adjustment is done with a hydraulic piston to enable the load piston to work witin larger stroke limits. Locking pins are used to manually fix the upper beam on the columns.
For the tests acc. to EN 1916 and also ASTM, UTC-5805.PVD1 , UTC-5808.PVD1 and UTC-5810.PVD1 Machines have an advanced motion controlled power pact.
V-shaped base chassis should be ordered separately.
Apart from the machines below, Utest produces concrete pipe testing machines in the requested length and diameter range.
