Pinhole Test Apparatus
Water flowing through fine-grained soils with high sodium content makes them highly erodible.
The UTS-1500 and UTS-1504 Pinhole Test Apparatus are used for evaluating the erodibility of clay soils by flowing water through a small hole that is drilled through the compacted specimen.
The apparatus consist of a cylindrical plexiglass body (container) fitted top cap with a water inlet and the base cap with an outlet connection, a plastic nipple, a plastic centering guide, a wire punch (1.0 mm), a stand to support the apparatus with 1100mm scale and standpipe tube(Ø4mm IDx6mm OD), four pcs wire mesh, 1,5m pvc tubing with a valve, 10ml, 25ml and 50 ml graduated glass measuring cylinders and an anvil with a tamper (fit with the body of ordered apparatus).
Constant level water tank (UTS-1308) and de-airing water equipment should be ordered separately.
If required, different inner diameter plexiglass bodys with caps can be produced.
