Muffle Furnace
Genel Bilgi
UTD-1462 Muffle Furnace is used for determining the loss on ignition and insoluble residue of cement and building lime.
Daha Fazla Bilgi Al
- Ürün Hakkında
- Ürünler
- Teknik Özellikler
- Standartlar
- Dokümanlar
Ürün Hakkında
Muffle Furnace
UTD-1462 Muffle Furnace is used for determining the loss on ignition and insoluble residue of cement and building lime.
Working temprature and time can be programmed with PID digital control system.
Ürünler
Ürünler
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTD-1462 | Muffle Furnace 6 lt. 1200°C Max. Temperature with Programmable Timer, 20-240 V 50-60 Hz |
Teknik Özellikler
Teknik Özellikler
|
Temperature Controller |
PC 442/2 |
|---|---|
|
Max. Temperature |
1200 °C |
|
Max. Continuous Temperature |
1150 °C |
|
Temperature Deviation at Set Point |
± 2°C |
|
Heat Up Time to Max. Temperature |
50. min |
|
Internal Volume |
6 L |
|
Phase |
1 |
|
Internal Dimension |
140x180x200 mm |
|---|---|
|
External Dimension |
650x550x580 mm |
|
Weight (approx.) |
56 kg |
|
Power |
2000 W |
Standartlar
Standartlar
EN 196-2; ASTM C25, C115Aksesuarlar
Aksesuarlar
| Product Code | Description | Number | Process |
|---|
Dokümanlar
Dokümanlar
