Magnesium Sulphate / Sodium Sulphate Test Water Bath
Genel Bilgi
Magnesium Sulphate and Sodium Sulphate Tests are used for determining the soundness of aggregates when subjected toweathering action such as freezing and thawing in concrete or other applications. Only the specific products are listed above for the test. It should be noted that other equipment like ovens, sieves, balances etc. are also required to perform these tests.
Daha Fazla Bilgi Al
- Ürün Hakkında
- Ürünler
- Teknik Özellikler
- Standartlar
- Aksesuarlar
- Dokümanlar
Ürün Hakkında
Magnesium Sulphate / Sodium Sulphate Test Water Bath
Magnesium Sulphate and Sodium Sulphate Tests are used for determining the soundness of aggregates when subjected toweathering action such as freezing and thawing in concrete or other applications. Only the specific products are listed above for the test. It should be noted that other equipment like ovens, sieves, balances etc. are also required to perform these tests.
Sodium Sulphate can be used instead of Magnesium Sulphate according to the ASTM standard. UTGG-2415 Hydrometer 1100-1200 g/ml is required for the test with Sodium Sulphate Test.
The temperature of test solution is automaticly adjusted to required temperature with a microprocessor type sensor placed in the water bath. The second sensor can be placed in the lever lid containers or stainless steel immersion container by user.The temperature data of water bath and the temperature test solution are displayed in real time on digital screen with 0.1°C resolution.
Homogenous temperature distribution can be obtain with water circulation pump that makes feedback.
Magnesium Sulfate / Sodium Sulfate Test Water Bath has (20±2) 0C accuracy and can be used as general purpose water bath that temperature is between 15-60 °C temperature
Supplied complete with the immersion container with the cover.
Density Baskets, Container for Density Basket, Hydrometer, Magnesium or Sodium Sulphate should be ordered seperately.
UTW-1008 UTGH-1460
Ürünler
Ürünler
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTA-0840 | Magnesium Sulphate/Sodium Sulphate Test Water Bath, 220-240 V 50-60 Hz, 1ph. | ||
| UTA-0840-N | Magnesium Sulphate/Sodium Sulphate Test Water Bath, 110-120V 60 Hz, 1ph. |
Teknik Özellikler
Teknik Özellikler
|
Products Code |
Dimensions |
Weight |
|---|---|---|
|
UTA-0840 |
550x750x950 mm |
75 kg |
|
Chamber of Bath |
560x460x500 mm |
-- |
|
UTW-1008 |
Ø160x200 mm |
0,20 kg |
|
UTGH-1460 |
Ø160x200 mm |
0,50 kg |
|
UTW-1017 |
Ø230x260 mm |
0,80 kg |
|
UTGH-1465 |
Ø280x300 mm |
1 kg |
|
UTGG-2415 |
20x20x330 mm |
0,10 kg |
|
UTGG-2420 |
20x20x330 mm |
0,10 kg |
|
Immersion Container |
330x330x330 mm |
4 kg |
Standartlar
Standartlar
EN 1367-2, 13450; ASTM C88; UNI 8520-10; UNE 7136Aksesuarlar
Aksesuarlar
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTW-1008 | Density Basket, Ø120 x 160 mm deep, 3,35 mm mesh, EN/ASTM | ||
| UTGH-1460 | Container for Density Basket, Ø160 x 200 mm deep, Aluminium, for UTW-1008, EN/ASTM | ||
| UTW-1017 | Density Basket, Ø230 x 260 mm deep, 4 mm stainless steel mesh, EN | ||
| UTGH-1465 | Container for Density Basket Ø270 x 300 mm deep, Aluminium, for UTW-1017, EN | ||
| UTGG-2415 | Hydrometer 1100-1200 g/ml, ASTM | ||
| UTGG-2420 | Hydrometer 1200-1300 g/ml, EN/ASTM | ||
| UTGC-0850 | Sodium Sulphate, 1 kg, ASTM | ||
| UTGC-0915 | Magnesium Sulphate, 1 kg, EN/ASTM |
Dokümanlar
Dokümanlar
