ASTM & AASHTO LOW CAPACITY AUTOMATIC COMPRESSION TESTING MACHINES FOR CYLINDERS
Models	UTC-4601.FPR	UTC-4701.FPR	UTC-4602.FPR	UTC-4702.FPR
Product Photo
Capacity	600kN (135000 lbf)	1100 kN (245000 lbf)	600kN (135000 lbf)	1100 kN (245000 lbf)
Frame Type	Welded Steel	Welded Steel	Welded Steel	Welded Steel
Lower Bearing Block, Dimensions (D)	Ø105 mm (4,13”)	Ø105 mm (4,13”)	Ø 165 mm (6,50")	Ø 165 mm (6,50")
Upper Bearing Block, (With Spherically Seating Assembly) Dimensions (C)	Ø 165 mm (6.5”)	Ø 165 mm (6.5”)	Ø 165 mm (6,50")	Ø 165 mm (6,50")
Surface Hardness of Bearing Blocks	≥ 55 HRC	≥ 55 HRC	≥ 55 HRC	≥ 55 HRC
Flatness Tolerance	0,02 mm / 150 mm (0,001”/6”)	0,02 mm / 150 mm (0,001”/6”)	0,02 mm / 15 0mm (0,001”/6”)	0,02 mm / 150 mm (0,001”/6”)
Piston Diameter	150 mm (5,9”)	190 mm (7,48”)	150 mm (5,9”)	190 mm (7,48”)
Piston Stroke	50 mm (1,97”)	50 mm (1,97”)	50 mm (1,97”)	50 mm (1,97”)
Maximum Vertical Clearance Between Bearing Blocks (E)	340 mm (13,4”)	380 mm (15”)	340 mm (13,4”)	380 mm (15”)
Horizontal Clearance (B)	230 mm (9,06”)	270 mm (10,6”)	230 mm (9,06”)	270 mm (10,6”)
For Cylinder Specimens Sizes	Ø100x200 mm (4”x8”)	Ø100x200 mm (4”x8”)	Ø100x200 mm (4”x8”) Ø150x300mm(6”x12”) (**)	Ø100x200 mm (4”x8”) Ø150x300mm(6”x12”) Ø160x320 mm
Power	550 W	550 W	550 W	550 W
Oil Capacity	20 L (0,7 ft³)	20 L (0,7 ft³)	20 L (0,7 ft³)	20 L (0,7 ft³)
Maximum Working Pressure	340 Bar	390 Bar	340 Bar	390 Bar
Dimensions (wxlxh) (Axd*xF)	640x454x922mm (25,2”x17,87”x36,3”)	680x454x1042mm (26,77”x17,87”x41,02”)	640x454x922mm (25,2”x17,87”x36,30”)	680x454x1042mm (26,77”x17,87”x41,02”)
Weight	365 kg (805 lbs)	463 kg (1020 lbs)	376 kg (830 lbs)	474 kg (1045 lbs)
Pedestal (Optional)	UTC-4680	UTC-4680	UTC-4680	UTC-4680
(d) depth () Limited by capacity of the frame The Machines are supplied complete with; • UTC-4601.FPR and UTC-4602.FPR : 100 mm (3,93”), 50 mm (1,97”), 30 mm (1,2”) height x Ø165 mm (Ø 6,5”) distance pieces* • UTC-4701.FPR and UTC-4702.FPR: 100 mm (3,93”), 50 mm (1,97”), 2 pcs. 30 mm (1,2”) height x Ø165 mm (Ø 6,5”) distance pieces • Removable transparent front and rear safety doors • The front safety doors have an automatic safety device to stop the machine if the door is opened during a test

ASTM & AASHTO LOW CAPACITY AUTOMATIC COMPRESSION TESTING MACHINES FOR CYLINDERS

Models

UTC-4601.FPR

UTC-4701.FPR

UTC-4602.FPR

UTC-4702.FPR

Product


UTC 4601.FPR 600 kN 105 mm

UTC 4701.FPR 1100kN 105mm

UTC 4602.FPR 600 KN 165mm

UTC 4702..FPR 1100kN 165mm

Capacity

600kN (135000 lbf)

1100 kN (245000 lbf)

600kN (135000 lbf)

1100 kN (245000 lbf)

Frame Type

Welded Steel

Lower Bearing Block, Dimensions (D)

Ø105 mm (4,13”)

Ø 165 mm (6,50")

Upper Bearing Block, (With Spherically Seating Assembly) Dimensions (C)

Ø 165 mm (6.5”)

Ø 165 mm (6,50")

Surface Hardness of Bearing Blocks

≥ 55 HRC

Flatness Tolerance

0,02 mm / 150 mm (0,001”/6”)

0,02 mm / 15 0mm (0,001”/6”)

0,02 mm / 150 mm (0,001”/6”)

Piston Diameter

150 mm (5,9”)

190 mm (7,48”)

150 mm (5,9”)

190 mm (7,48”)

Piston Stroke

50 mm (1,97”)

Maximum Vertical Clearance

Between Bearing Blocks (E)

340 mm (13,4”)

380 mm (15”)

340 mm (13,4”)

380 mm (15”)

Horizontal Clearance (B)

230 mm (9,06”)

270 mm (10,6”)

230 mm (9,06”)

270 mm (10,6”)

For Cylinder

Specimens Sizes

Ø100x200 mm

(4”x8”)

Ø100x200 mm

(4”x8”)

Ø100x200 mm (4”x8”)
Ø150x300mm(6”x12”)

(**)

Ø100x200 mm (4”x8”)
Ø150x300mm(6”x12”)

Ø160x320 mm

Power

550 W

Oil Capacity

20 L (0,7 ft³)

Maximum Working Pressure

340 Bar

390 Bar

340 Bar

390 Bar

Dimensions (wxlxh) (Axd*xF)

640x454x922mm

(25,2”x17,87”x36,3”)

680x454x1042mm

(26,77”x17,87”x41,02”)

640x454x922mm

(25,2”x17,87”x36,30”)

680x454x1042mm

(26,77”x17,87”x41,02”)

Weight

365 kg (805 lbs)

463 kg (1020 lbs)

376 kg (830 lbs)

474 kg (1045 lbs)

Pedestal (Optional)

UTC-4680

(d*) depth

(**) Limited by capacity of the frame

The Machines are supplied complete with;

• UTC-4601.FPR and UTC-4602.FPR : 100 mm (3,93”), 50 mm (1,97”), 30 mm (1,2”) height x Ø165 mm (Ø 6,5”) distance pieces

• UTC-4701.FPR and UTC-4702.FPR: 100 mm (3,93”), 50 mm (1,97”), 2 pcs. 30 mm (1,2”) height x Ø165 mm

(Ø 6,5”) distance pieces

• Removable transparent front and rear safety doors

• The front safety doors have an automatic safety device to stop the machine if the door is opened during a test
