De-Airing Water Systems
Genel Bilgi
The UTS-De-Airing Water Apparatus is a compact and self-contained equipment which can de-air water quickly for geotechnical test methods. The apparatus used in conjunction with the de-airing tank (UTS-1330). Air is removed from the water by a vacuum system. De-airing tank should be ordered separately.
Daha Fazla Bilgi Al
- Ürün Hakkında
- Ürünler
- Teknik Özellikler
- Standartlar
- Aksesuarlar
- Dokümanlar
Ürün Hakkında
De-Airing Water Systems
The UTS-De-Airing Water Apparatus is a compact and self-contained equipment which can de-air water quickly for geotechnical test methods. The apparatus used in conjunction with the de-airing tank (UTS-1330). Air is removed from the water by a vacuum system. De-airing tank should be ordered separately.
The first option for de-airing water;
- De-Airing Water Apparatus UTS-2418
- De-Airing Water Tank (UTS-1330)
- Vacuum Control and Water Connection Panel with Regulator and Vacum Gage Manometer (UTGE-3580) (These panel is optional)
- Plastic Hose (UTGP-1140)
The second option for de-airing water;
- Vacuum Pump (UTGE-3505),
- Filter Flask (UTGG-2016) or Air Drying Unit / Water Trap (UTGE-3570)
- De-Airing Water Tank (UTS-1330)
- Vacuum Control and Water Connection Panel with Vacum Gage Manometer (UTGE-3580) (These panel is optional)
- Plastic Hose (UTGP-1140),
By using UTGE-3580 Vacuum Control and Water Connection Panel, vacum pressure degree can be regulated . By using UTGE-3580 de-aring water equipment can be used without repeated assembling the hoses.The panels are supplied with 3m hose (UTGP-1140).
Ürünler
Ürünler
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTS-2418 | De-Airing Water Apparatus, 230V, 50Hz, 1ph |
Teknik Özellikler
Teknik Özellikler
|
Product Code |
Dimensions |
Weight (approx.) |
|---|---|---|
|
UTS-2418 |
240x460x380 mm |
15 kg |
|
UTGE-3580 |
300x400x100 mm |
5 kg |
|
UTS-1330 |
200x300x250 mm |
3 kg |
|
UTGG-1442 |
120x120x220 mm |
0.5 kg |
|
UTGE-3505 |
290x120x220 mm |
7 kg |
|
UTGE-3570 |
70x70x240 mm |
0,5 kg |
Standartlar
Standartlar
Aksesuarlar
Aksesuarlar
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTS-1330 | De-Airing Water Tank, 7 L. | ||
| UTGE-3580 | Vacuum Control and Water Connection Panel with Vacum Gage Manometer | ||
| UTGE-3505 | Vacuum Pump 51 L/min. Capacity, 220-240 V 50-60 Hz | ||
| UTGG-2015 | Filter Flask for Vacuum, 2000 ml | ||
| UTGE-3570 | Air Drying Unit / Water Trap, Vacuum Type | ||
| UTGP-1140 | Plastic Hose, Ø8mm OD, 3 m |
Dokümanlar
Dokümanlar
