Multiplex Universal Electromechanic Testing Machine
UTM-0108.SMPR Multiplex Universal Electromechanic Testing Machine have been designed for multipurpose testing applications that require testing in multiple areas such as road construction projects, education laboratories. By displacement/deformation control, the MULTIPLEX with appropriate accessories can perform soil tests such as CBR, triaxial (UU, CU and CD), UC, asphalt tests such as Marshall stability, semi circular bearing strength(SCB), indirect tensile (IDT),
The machine has a frame capacity is 50 kN (11.200 lbf) with adjustable upper cross beam. This versatile digital loading frame features a microprocessor controlled drive system with an advanced servo motor enabling the operator to easily set any test speed via the UTouch screen comprises adjustment buttons such as “test type”, “pace rate”, “automatic”, “manuel”, start”, “stop”, ““down”, “up” as well as other user defined test parameters.Load and displacement values are collected by UTouch Control Unit and transferred to PC for further processing.
The load is applied by a mechanical jack that is driven by a servo motor with closed loop controlled.
Load cell/s and other suitable test accessories to perform test/s should be ordered separately.The accessories are specified in the table below.
UTM-0108.SMPR Multiplex is supplied complete with;
- 50x0,001 mm Linear Potentiometric Displacement Transducer, (UTGM-0064) and its holders (UTM-0114 and UTAS-1060)
- Lower compression platen
Teknik Özellikler
- Max. Capacity : 50 kN
- Test speed range: 0.2 to 51 mm/min
- Power : DC motor 750 W
- Horizontal clearance : 260 mm
- Max. vertical daylight (without accessories) : 720 mm
- Platen travel : 90 mm
- Overall dimensions (lxwxh) : 477 x 620 x 1190 mm
- Net weight approx. : 65 kg
For detailed
PLEASE see the of section “Universal Testing System” for details of the properties UTM-0108.SMPR
