Abrasion Testing Machine According to Böhme
Genel Bilgi
UTA-0615 the Abrasion Testing Machine according to Böhme is used for determining the abrasion resistance of concrete and natural stone products used for internal or external paving.
Daha Fazla Bilgi Al
- Ürün Hakkında
- Ürünler
- Teknik Özellikler
- Standartlar
- Aksesuarlar
- Dokümanlar
Ürün Hakkında
Abrasion Testing Machine According to Böhme
UTA-0615 the Abrasion Testing Machine according to Böhme is used for determining the abrasion resistance of concrete and natural stone products used for internal or external paving.
The machine consists of a grinding wheel of approx. 750 mm diameter, a removable testing weight of 30 kg and a clamping device for the sample. The machine is equipped with an adjustable counter (30 ± 1 r.p.m.) and an automatic cut-off system which stops the machine after 22 rotations.
UTA-0616 Abrasive Sand should be ordered separately.
Ürünler
Ürünler
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTA-0615-T | Abrasion Testing Machine According to Böhme, 220-240 V 50 Hz, 1 ph (60 Hz version is available upon request) |
Teknik Özellikler
Teknik Özellikler
|
Dimensions |
810x1460x1270 mm |
|---|---|
|
Weigh (approx.) |
210 kg |
|
Power |
750 W |
Standartlar
Standartlar
EN 1338, 1339, 1340Aksesuarlar
Aksesuarlar
| Product Code | Description | Number | Process |
|---|---|---|---|
| UTA-0616 | Abrasive Sand, 50 kg pack for UTA-0615 |
Dokümanlar
Dokümanlar
