The UTW-1000 Specific gravity framework is used to find the volume occupied by the aggregate in various mixtures containing coarse aggregates, with the aid of a scale and a wire basket.It is also used to find the volume of irregularly shaped natural stone and similar materials.
The UTW-1000 Specific gravity framework is used to find the volume occupied by the aggregate in various mixtures containing coarse aggregates, with the aid of a scale and a wire basket.It is also used to find the volume of irregularly shaped natural stone and similar materials.
The lower part of the frame incorporates a moving platform, which carries the water tank allowing the test specimens to be weighed in both air and water.
The frame can be used with any type of electronic balance fitted with under-bench weighing facility
Balance, cradle and density basket should be ordered separately.
The Specific Gravity Frame is supplied complete with;
UTW-1005 UTW-1010 UTW-1003
Product Code | Description | Number | Process |
---|---|---|---|
UTW-1000 | Specific Gravity Frame |
Dimensions |
400x560x1000 mm |
---|---|
Weight (approx.) |
26 kg |
Product Code | Description | Number | Process |
---|---|---|---|
UTW-1003 | Plastic Water Tank | ||
UTW-1005 | Cradle for Hardened Concrete Specimens | ||
UTW-1008 | Density Basket, 120 mm dia x 160 mm deep, 3.35 mm stainless steel mesh | ||
UTW-1010 | Density Basket Ø 200 mm x 200 mm 3.35 mm stainless steel mesh | ||
UTW-1012 | Density Basket, 250 mm dia x 250 mm 3.35 mm (No.6) stainless steel mesh | ||
UTW-1015 | Density Basket, 200 mm dia x 180 mm 2.00 mm (No:10) stainless steel mesh |
